Progressive Die & Metal
Our Progressive Die, Deep Draw and Compound stamper has been in business for over 76 years. They have NO DEBT and they have invested heavily in SERVO driven stamping presses. This allows us to be extremely competitive…
Compound die and metal stamping services are often used when medium to low volume stamped parts need to be produced. Compound stamping dies can be made for a lower cost than is required for a complete progressive die.
Compound dies can be used to produce a wide variety of components but they are commonly used for flat blanks or drawn cups as well as rings depending on the complexity of the stamping. Compound tooling is always less expensive than progressive dies but in some cases capable of consistently holding very tight tolerances. If a part just needs to be blanked out, then compound dies can hold a tight tolerance and requires a much lower tooling cost than a progressive die. Current parts that need to be run through multiple different dies to reach their final desired shape would be considered (Compound dies).
If you have a family of medium to low volume parts that are very similar in configuration, this can also be a great scenario for using Compound stampings. For customers that have many parts that require multiple hits in different dies, our manufacturing facility has a very unique set of machines to run these types of parts very competitively. We can set up your compound dies in our line of four 275 ton AIDA SERVO presses that can act like a 1,100-ton compound line for the right project. This line of four presses have roller conveyors that transport parts from one press to the next.
Advantages of using Servo Presses on Compound stampings: Due to the infinite, optional stroke profiles that a servo press can be programmed for, it is often capable of running compound stampings as well as problem stampings more accurately and more efficiently than a conventional stamping press. In many cases eliminating operations as well as being able to run at increased speeds.
Capabilities
| Supply Chain Security | Our facility has been in business for 76 years & has ZERO DEBT. |
| Presses | 36 Presses ranging from 10 tons to 325 tons including 6 Servo presses. |
| Material Thicknesses | .010" to .325" |
| Raw Materials | Steel, Carbon Steel, Stainless Steel, Aluminum, Brass, Hastelloy, Bronze, Beryllium Copper, Titanium, Platinum and many others. |
| Industries Served | Aerospace, Agriculture, Appliance, Automotive, Communications, Construction, Electric Motors, Electronics, Emerging Energies, Fluid Powers, Furniture, Green Building, Hardware, Industrial Packaging, Locomotive, Marine, Medical, Military, Natural Gas, Plumbing as well as Truck & Tractor Trailer and many others. |
| Common Applications | Covers, caps, seals, clamps, heat sinks, cups, tags, shields, cans, clamps, retainers, plates, diffusers, diaphragms, and many others. |
| Quality | ISO 9001:2015 Certified. |
| Finished Goods Warehouse | We have a separate 30,000 sqft finished goods warehouse located 5 miles from our facility. We ship to all our customers via VMI, KAN BAN, EDI & JIT. This works great for Disaster Recovery plans. |
Lowest Total Cost
Design For Manufacturability
Technology & Automation
Increased Turns & Reduced Lead Times
We have the ability to build and maintain all of our dies.
We also can use outside tool makers if required.
Benefits:
1. The ability to build less expensive tooling than progressive dies and still produce the stamped part that meets the customer's requirements.
2. The ability to take over compound dies from other suppliers and run them in our 4 SERVO press line that is designed to run compound dies. The parts get produced in unison at a much-reduced cost.
3. We have a line of four 275 ton Servo Aida presses that can act like a 1,100-ton transfer/Compound stamping line for the right project. These presses have roller tables between each press to allow our team members to quickly move apart through multiple different die hits to provide a finished part.
Common Applications
Include almost any application requiring metal.
- Brackets
- Seals
- Cups
- Tags
- Shields
- Clamps
- Latches
- Retainers
- Covers
- Plates
- Clevises
- Relay frames
- Diffusers
- Diaphragms
- Heat sinks
- Frames
- Washers
- ..and many others.
Additional Information
- Our stamping facility has been in business for 76 years and has NO debt.
- We have 36 presses ranging from 10 tons to 320 tons, including 6 SERVO presses to meet your manufacturing needs. Some of the presses are designed for running Compound Stampings and some of them are designed for running progressive die stampings.
- Our engineers have decades of experience as well as the latest CAD software to partner with our customers to help design the best stamping die for your application.
- Depending on the part requirements, the type of material required as well as the volumes, we will suggest if a part is a good fit to be produced using a Compound stamping die.
- We also have a state-of-the-art tool room to build as well as maintain all of our dies in-house. The combination of the newest press technologies, over 76 years of experience as well as 5 full-time toolmakers in-house, allows us to be extremely competitive with both our tooling and our piece part pricing.
- We are over 99% on-time deliveries to all of our customers.
- We have single and double-digit PPM numbers with our customers.
- Our (4) 275 ton AIDA Servo line can act like a 1,100-ton transfer line for some projects.
- Engineering Support & Program Management. Our facility has a wide variety of engineers as well as 5 tool makers in-house. This allows our entire TEAM to work closely with your engineers and materials team to develop a stamping die that meets your requirements at the Lowest Total Cost.
- VMI (Vendor Managed Inventory): We have years of experience doing Vendor Managed Inventory and we can ship parts via JIT, EDI, Kan Ban or per your delivery schedules on a daily basis out of our finished goods warehouse.
- Open To Take Over Dies: Our facility is open to take over dies & has grown substantially through vendor consolidation programs. Many of our customers have consolidated their stamping supply base from many different suppliers to our facility and possibly one other.
- Finished Goods Warehouse: Our stamping facility has a separate 30,000 square foot finished goods warehouse located about 5 miles from our facility. This warehouse is great for customers who are required to have disaster recovery plans.
- We Welcome Take over Dies: We have 5 in house toolmakers who are always ready and willing to take over dies from other stamping suppliers. In our 76 years of business, we have been awarded many consolidation programs. We are ready to assist you and do any retrofitting or tooling adjustments that may be required to your dies.
- We take complete responsibility for delivering turnkey line-ready Tier 1 parts. We have decades of experience managing, all the raw materials, heat treating, plating, taping as well as assembly operations.
- We can be extremely competitive with both our tooling and our piece part pricing.
- We have been awarded countless Quality and delivery awards.
- Our facility shows and audits extremely well.
Common Applications of Compund Stampings:
- Covers
- Caps
- Seals
- Clamps
- Heat sinks
- Cups
- Tags
- Shields
- Cans
- Clamps
- Retainers
- Plates
- Diffusers
- Diaphragms,
- ..and many others.
Commonly used materials include:
- Steel
- Carbon Steel
- Stainless Steel
- Aluminum
- Brass
- Hastelloy
- Bronze
- Beryllium Copper
- Titanium
- Platinum
- ..and many others.
- Aerospace
- Agriculture
- Appliance
- Automotive
- Communications
- Construction
- Electric Motors
- Electronics
- Emerging Energies
- Fluid Powers
- Furniture
- Green Building,
- Hardware
- Industrial Packaging
- Locomotive
- Marine
- Medical
- Military
- Natural Gas
- Plumbing
- Truck & Tractor Trailer
- ..and many others.
Compound stamping is when you use multiple different dies to obtain a finished stamped part. You can produce deep-drawn parts using compound dies as well. A deep-drawn part is when the depth of the drawn cup exceeds its diameter. Deep drawing can be performed in progressive die tooling as well as multiple-stage compound die tooling. It all depends on the depth of the cup. Deep Drawn parts can be produced on conventional flywheel presses as well as Servo presses.
Just like progressive die stampings, deep-drawn stampings use custom dies. The custom dies are used to cut, form and shape rolled sheets of metal using a stamping press. The stamping die is comprised of many individual workstations that help develop the finished part. Each station works in unison to progressively complete each required operation that is necessary to produce a finished part.
The custom dies can perform a wide variety of operations such as cutting, coining, forming, bending, extruding, drawing, embossing, tapping, assembly as well as many others.
- It is one of the most cost-effective manufacturing processes available to produce metal components in a wide variety of shapes and sizes, using almost any material you can imagine.
- You can form as well as draw material to create different material thicknesses, shapes, corners and radiuses to meet your required application.
- The tooling is relatively inexpensive and can last for decades.
- You can convert parts from a wide variety of other metal forming practices such as fabrications, castings, forgings, powdered metal as well as weldments into parts produced as deep-drawn stamping.
Explore Other Stamping Solutions
Explore Stampings
Custom Deep Drawn
A Deep Drawn stamping is when the depth of the drawn cup exceeds its diameter.
Four Slide & Multi Slide
Depending on the size of the part as well as the part complexity, four-slide & multi-slide machines can often produce parts for a lower total cost than progressive dies.
View Some of Our Case Studies
Converted a steel machined casting into a steel stamping using a Compound stamping die. The end result is a huge cost reduction.
